Mekotronics A58-Pro Rockchip RK3588 Specifications
1. Mekotronics A58-Pro introduction video:
https://www.youtube.com/watch?v=5YWMrxUf2mg
2. Mektronics A58 Pro description:
Mekotronics A58-Pro, is using Rockchip RK3588 chipset, which is 8nm made and 8-core CPU, 4 cores Cortex A76 and 4 cores of Cortex A55.
Mekotronics A58-Pro, internally integrated 6.0 tops NPU can meet the edge computing needs of most terminal devices.
The model A58-Pro has diverse interfaces:
G-LAN network, Micro SD card, USB3.0, Audio port, and biggest feature is multiple video inputs: HDMI input, SDI input which can be used as an broadcasting and live-streaming device.
The A58-Pro device is with LPDDR4X, optional size from 4G to 16G; And its ROM is EMMC 5.1, optional from 32G, 64G and 128G
And with its cold mount, you can also install the R58-SDI device on your camera directly, for easy broadcasting and live-streaming at online social platforms.
3. Mekotronics A58-Pro specs:
CPU | Rockchip RK3588, Octa-core (quad-core Cortex A76 and quad-core Cortex A55) |
CPU frequency | Quad-core Cortex A76 @2.4Ghz Quad-core Cortex A55 @1.8Ghz |
GPU | Mali-G610 GPU, OpenGL ES 1.1/2.0/3.2, OpenCL 2.2, Vulkan 1.2 |
| Embedded high-performance 2D acceleration hardware |
| 8K 10 bit decoder, 8K encoder |
NPU | 6.0 TOPS NPU |
DDR | LPDDR4X (4G, 8G, 16G optional) |
OS | Android and Linux |
Internal storage | eMMC5.1 (32GB, 64GB, 128GB optional) |
Display output | HDMI and EDP touch screen |
HDMI input | HDMI and SDI inputs |
Ethernet | G-LAN network |
WiFi | WiFi 6, IEEE 802.11 a/b/g/n/ac/ax MIMO |
USB | USB3.0, USB2.0, Tpye-C |
Mini PCIe | Mini PCIe for 4G LTE/GPS module |
SIM card | Support Nano SIM card for 4G |
Card | Micro SD card slot |
Audio | Support audio jack |
Industrial | GPIO |
DC power | 12V 2Ah |
